Silva 70P

70P is a bulkhead mount compass designed for yachtsmen that demand absolute accuracy and a steady card in all conditions. The compass handles unlimited slope of the keel line and a 30º heeling angle. The curved lubber line enables swift and clear reading at a glance without parallax correctos. With a main steering scale on the horizontal part and direct reading on the vertical edge, 70P is ideal for boats with a sitting as well as a standing helmsman. It can be mounted at most angles and its compact size (70 mm) makes it suitable for smaller boats.

Features:

– Double scales: Can be read from front and above

– Suitable for all boats: Fits in all boat types

– Curved lubber lines: Accurate reading from different angles

– Compact size: Small and flexible

Specifications:

– Accuracy: ± 1° (17.8 mils)

– Apparent card diameter: 70mm (2.7 inch)

– Built-in compensator: Optional

– Card type: Cone

– Compatibility: Kayaks, Powerboats, Sailboats

– Dimensions: 95x72mm

– Gimballed cradle: No

– Heeling angle: Roll: 30° Pitch: 30°

– Heeling angle scale: No

– Illumination: Optional

– Lubber lines: Centre

– Material: ABS, Acrylic

– Memory ring: No

– Mounting: Bulkhead

– Mounting angle: +10° to +110°

– Temperature operating range: -10°C to +70°C

– Variant: Magnetic Equator, Magnetic South, Magnetic North

– Weight: 344g
